HW-CMMConnectoc, HW-222S02MM, 2mm Pitch

  • HW-CMMConnectoc, HW-222S02MM, 2mm Pitch
  • HW-CMMConnectoc, HW-222S02MM, 2mm Pitch
  • HW-CMMConnectoc, HW-222S02MM, 2mm Pitch
  • HW-CMMConnectoc, HW-222S02MM, 2mm Pitch
Place of Origin China
Brand Name HIGH WOOD
Certification AS9001
Model Number HW-222S02MM
Minimum Order Quantity 100PCS
Price 10＄--150＄
Packaging Details standard export package
Delivery Time 2--9weeks
Payment Terms L/C, Western Union, T/T
Supply Ability 100,000pcs per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
All Contacts 3 A Max.@25℃ 2.2A Max.@85℃ Working Voltage(see Level) Tested At 800 V DC
Proof Voltage Tested At 1 200 V DC Contact Resistance(initially) Max .10 MΩ
Insulation Resistance 1 000 ΜΩ Min. Mechanical Operations Up To 2500 Cycles
High Light

HW-CMMConnectoc

,

HW-222S02MM

,

2mm Pitch Custom Connectors
Leave a Message
Product Description

HW-222S02MM:





CMM 220 series:2 rows - from 4 to 60 LF contacts,or up to 15 HF or HP contacts(series30),CMM has been developed for the aerospace,avionics,instrumentation & control,defence and transportation markets,with applications that induce IFES,HUDs,fight controls,FADEC units,radars,missiles, electro-optical sighting systems,satellites,mobile radios,power supplies,UAVs and engine controls.It is also used engine controls.



HW-CMMConnectoc, HW-222S02MM, 2mm Pitch 0



Type L
S 24-28
C 22

B





FIXING HARDWARE FOR CMM 220 FEMALE:

REFERENC ASSEMBLY ON PCB OVERALL DIMENSIONS RECOMMENDATION

M11



 HW-CMMConnectoc, HW-222S02MM, 2mm Pitch 1

HW-CMMConnectoc, HW-222S02MM, 2mm Pitch 2



M11 :

CMM Female :

Y-YL-T-S-C-E

(D :straight)





MALE STRAIGHT ON CABLE P/N 30-33xx (solder or crimp):



Loaded Unloaded Ampere Cable A ØB ØC Length D hole Length E body Length F conductor Solder Crimp by HX3 Hexagone size/Dies Crimp by AF8
      AWG 20 AWG 18 AWG 16 AWG 14 AWG 12
3305 30-3305 5A ×         1,1mm

1,65

mm

 6,2mm 6,7mm 4,5mm OK Hex.1,9 mm/C14923 OK
3308 30-3308 8A   ×       1,35mm

1,85

mm

 6,2mm 6,7mm 4,5mm OK Hex.1,9 mm/C14923 OK
3310 30-3310 10A × × ×     1,7mm   6,2mm 6,7mm 6mm OK   OK
3315 30-3315 15A       ×   2mm   6,2mm 6,7mm 6mm OK   OK
3320 30-3320 20A         × 2,6mm   6,2mm 6,7mm 5,3mm OK   OK





Prodacts showing:



HW-CMMConnectoc, HW-222S02MM, 2mm Pitch 3



HW-CMMConnectoc, HW-222S02MM, 2mm Pitch 4
