5-pin M12 connector, straight injection-molded female connector with solder cups, without shielding

  • 5-pin M12 connector, straight injection-molded female connector with solder cups, without shielding
  • 5-pin M12 connector, straight injection-molded female connector with solder cups, without shielding
  • 5-pin M12 connector, straight injection-molded female connector with solder cups, without shielding
  • 5-pin M12 connector, straight injection-molded female connector with solder cups, without shielding
Place of Origin China
Brand Name HIGH WOOD
Certification AS9001
Model Number 5-pin M12 connector, straight injection-molded female connector with solder cups, without shielding
Minimum Order Quantity 100pcs
Price 5＄--50＄
Packaging Details Standard export package
Delivery Time 2-9weeks
Payment Terms T/T, L/C, Western Union
Supply Ability 100，000pcs per month
Product Details
Rated Current 1.5A Conductor Resistance ≤ 5 MΩ
Insulation Resistance ≥100 MΩ Rated Voltage 30V
Ambient Temperature -40℃ ~ +90℃
Leave a Message
Product Description

5-pin M12 connector, straight injection-molded female connector with solder cups, without shielding



Product Features:

1.Threaded locking mechanism, shock-resistant locking design, 12mm threaded connector; Vertical solder cup soldering, unshielded design, injection-molded,structurally robust; resistant to vibration and tension

2.Quick plug-and-play, withstands repeated plug-and-unplug cycles, simple and convenient installation;Suitable for industrial sensors and fieldbus signal connections



Product Specifications:



Electrical Performance
Rated Current 5A
Rated Voltage 250V AC/rms 50Hz
Withstanding Voltage 1000V AC/rms 50Hz for one minute
Insulation Resistance 1000MΩ at 500V DC
Contact Resistance 20mΩ max
Mechanical Performance
Single Contact Insertion Force 1.19 lbs (0.54kg) max
Single Contact Extraction Force 0.13 lbs (0.06 kg) min
Mating Cycles ≥500 cycles
Environmental Performance
Operating Temperature -55 ~ 125℃



Product showing:

5-pin M12 connector, straight injection-molded female connector with solder cups, without shielding5-pin M12 connector, straight injection-molded female connector with solder cups, without shielding5-pin M12 connector, straight injection-molded female connector with solder cups, without shielding5-pin M12 connector, straight injection-molded female connector with solder cups, without shielding
