M5 Series Straight Waterproof 4-core Female Receptacle

  • M5 Series Straight Waterproof 4-core Female Receptacle
  • M5 Series Straight Waterproof 4-core Female Receptacle
  • M5 Series Straight Waterproof 4-core Female Receptacle
  • M5 Series Straight Waterproof 4-core Female Receptacle
Place of Origin China
Brand Name HIGH WOOD
Certification AS9001
Model Number M5 Series Straight Waterproof 4-core Female Receptacle
Minimum Order Quantity 100pcs
Price 5$-50$
Packaging Details Standard export package
Delivery Time 2-9weeks
Payment Terms T/T, L/C, Western Union
Supply Ability 50，000pcs per month
Product Details
Rated Current 5A Rated Voltage 250V AC/rms 50Hz
Withstand Voltage 1000V AC/rms 50Hz For One Minute Insulation Resistance 1000MΩ At 500V DC
Contact Resistance Max 20mΩ Single Contact Insertion Force Max 1.19 Lb (0.54 Kg)
Single Contact Withdrawal Force Min 0.13 Lb (0.06 Kg) Service Life ≥500 Cycles
Leave a Message
Product Description

M5 Series Straight Waterproof 4-core Female Receptacle



Product Introduction:



The M5 straight waterproof female connector belongs to the M series of miniature circular sensor connectors, featuring a threaded locking mechanism and a rear-mounting plate design. It is a specialized aviation connector designed for sensor signal transmission in compact devices. With its threaded locking structure, the connector is mounted on equipment panels to ensure stable signal connection, offering excellent waterproof performance, a small and compact size, and suitability for tight installation spaces.







Specifications:

Category Item Specification
Electrical Performance Rated Current 5A
  Rated Voltage 250V AC/rms 50Hz
  Withstand Voltage 1000V AC/rms 50Hz for one minute
  Insulation Resistance 1000MΩ at 500V DC
  Contact Resistance Max 20mΩ
Mechanical Performance Single contact insertion force Max 1.19 lb (0.54 kg)
  Single contact withdrawal force Min 0.13 lb (0.06 kg)
  Service Life ≥500 cycles
Environmental Performance Temperature Range -55 ~ 125℃
