M16 Waterproof Connector, 8-pin Female, Straight Cable Solder Connector
| Place of Origin | CHINA |
|---|---|
| Brand Name | HIGH WOOD |
| Certification | AS9001 |
| Model Number | M16 Waterproof Connector, 8-pin Female, Straight Cable Solder Connector |
| Minimum Order Quantity | 100PCS |
| Price | 5＄-50＄ |
| Packaging Details | standard expect package |
| Delivery Time | 2-9weeks |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 100，000pcs per month |
Product Details
| Operating Temperature Range | -25 ℃ ~ +85 ℃ | Mating Method | Threaded Coupling |
|---|---|---|---|
| Durability | ≥ 500 Mating Cycles | Ingress Protection Rating | IP67 |
Product Description
M16 Waterproof Connector, 8-pin Female, Straight Cable Solder Connector
Product Features:
✅ Excellent resistance to acids, alkalis, chemical cleaners and reagents; resistant to welding sparks, withstand frequent twisting and bending.
✅ Resistant to oil contamination, coolant, lubricants and emulsions; straight female and straight male connector structures available.
Product Specifications:
| Rated Current | 7A: 2/3/4PIN; 6A:5PIN; 5A: 6/7/8/12/14/16/19/24PIN |
|---|---|
| Rated Voltage | ≤200V: 2/3/4/5/6PIN; 60V: 7/8/12/14/16/19/24PIN |
| Contact Resistance | ≤7Ω: 2/3/4/5/6/7/8PIN; ≤10Ω: 12/14/16/19PIN; ≤12Ω: 24PIN |
| Insulation Resistance | ≥1500Ω: 2/3/4/5/6PIN; ≥1000Ω: 7/8/12/14/16/19/24PIN |
| Solder Cup Hole Diameter | 1.0mm: 2/3/4/5/6/7/8PIN; 0.8mm: 12/14/16/19PIN; 0.6mm: 24PIN |
| Contact Body Hole Diameter | 1.5mm: 2/3/4/5/6/7/8PIN; 1.0mm: 12/14/16/19PIN; 0.8mm: 24PIN |
| Coupling Method | Threaded Locking |
| Termination Method | Soldering |
| Mating Cycles | 500 times |
| Operating Temperature | -25℃ to +85℃ |
| IP Rating | IP67 |
Product showing.
