J599A8（ARINC801）series optical fiber connector，J599A8/26K1708N,

  • J599A8（ARINC801）series optical fiber connector，J599A8/26K1708N,
  • J599A8（ARINC801）series optical fiber connector，J599A8/26K1708N,
  • J599A8（ARINC801）series optical fiber connector，J599A8/26K1708N,
  • J599A8（ARINC801）series optical fiber connector，J599A8/26K1708N,
Place of Origin China
Brand Name HIGH WOOD
Certification AS9001
Model Number J599A8/26K1708N
Minimum Order Quantity 100pcs
Price 10$-150$
Packaging Details Standard export package
Delivery Time 2-9weeks
Payment Terms T/T, L/C, Western Union
Supply Ability 100，000pcs per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Plating Stainless Steel Passivation Type Of Connector Plug
Temperature -55℃ ~ +125℃ Endurance 500 Cycles
Insertion Loss ≤0.6dB Salt Spray 500h
Leave a Message
Product Description

J599A8/26K1708N

  • The interface size conforms to GJB599B(MIL-DTL-38999) Ⅲ series, and the performance conforms to ARINC801 standard
  • Suitable for aeronautical, electronic, shipboard and other systems for multi-channel optical communication
  • Adopts standard 1.25mm ceramic pin for high docking accuracy
  • Ceramic casing package array, can be disassembled and replaced as a whole, easy to use and maintain
  • Install and remove tool M81969/14-03 for contact parts, easy to operate


How to order:

J599A8（ARINC801）series optical fiber connector，J599A8/26K1708N, 0



Product pictures:

J599A8（ARINC801）series optical fiber connector，J599A8/26K1708N, 1J599A8（ARINC801）series optical fiber connector，J599A8/26K1708N, 2J599A8（ARINC801）series optical fiber connector，J599A8/26K1708N, 3J599A8（ARINC801）series optical fiber connector，J599A8/26K1708N, 4





Environmental:

Temperature :

-55℃ ~ +125℃

Salt spray:

ClassK,W:500h

ClassF:48h

Class MW: 192h (acidic atmosphere)
Air tightness (suitable for airtight switching socket): gas leakage rate ≤1×10-9Pa.m3/s, internal
and external pressure difference of 1 atmosphere


Mechanical:

Tensile force:: ≥68N (2mm contact jumper)
Endurance: 500 cycles
Vibration:

10Hz ~ 2000Hz, powerspectral density 0.4G²/Hz, acceleration
root mean square value 23.1G
Impact: Peak acceleration 2940m/s²,duration 3ms,Velocity change rate5.61m/s



Optical performance​:

Insertion loss: ≤0.6dB
RL (return loss):   ≥ 20dB@850nm；
≥ 40dB@1310nm





Plug dimensions:

J599A8（ARINC801）series optical fiber connector，J599A8/26K1708N, 5

Contact arrangement (take plug surface as an example):

J599A8（ARINC801）series optical fiber connector，J599A8/26K1708N, 6

                      17-08
