J599A8/26KD06N series optical fiber connector
| Place of Origin | China |
|---|---|
| Brand Name | HIGH WOOD |
| Certification | AS9001 |
| Model Number | 26KD06N |
| Minimum Order Quantity | 100pcs |
| Price | 10$-150$ |
| Packaging Details | Standard export package |
| Delivery Time | 2-9weeks |
| Payment Terms | T/T, L/C, Western Union |
| Supply Ability | 100，000pcs per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Tensile Strength | ≥68N (φ2mm Cable) | Insertion Loss | ≤0.5dB |
|---|---|---|---|
| Temperature | -55℃～+125℃ | Endurance | 500 Cycles |
| Return Loss | ≥20dB（850nm） | Salt Spray | Class K: 500h Class F: 48h Class W: 500h; Class MW: 192h (acidic Atmosphere) |
Product Description
J599A8/26KD06N
The interface size conforms to GJB599B(MIL-DTL-38999)Ⅲ series, and the performance conforms to ARINC801 standard
Suitable for aeronautical, electronic, shipboard and other systems for multi-channel optical communication
Adopts standard 1.25mm ceramic pin for high docking accuracy
Ceramic casing package array, can be disassembled and replaced as a whole, easy to use and maintain
Install and remove tool M81969/14-03 for contact parts, easy to operate
How to order:
Product pictures:
Environmental:
| Temperature : |
-55℃ ~ +125℃ |
| Salt spray: |
ClassK,W:500h ClassF:48h Class MW: 192h (acidic atmosphere) |
| Air tightness (suitable for airtight switching socket): | gas leakage rate ≤1×10-9Pa.m3/s, internal and external pressure difference of 1 atmosphere |
Mechanical:
| Tensile force:: | ≥68N (2mm contact jumper) |
| Endurance: | 500 cycles |
| Vibration: |
10Hz ~ 2000Hz, powerspectral density 0.4G²/Hz, acceleration |
| Impact: | Peak acceleration 2940m/s²,duration 3ms,Velocity change rate5.61m/s |
Optical performance:
| Insertion loss: | ≤0.6dB |
| RL (return loss): | ≥ 20dB@850nm； ≥ 40dB@1310nm |
Contact arrangement (take plug surface as an example):
