J599A6/26KB02N series optical fiber connector

Place of Origin China
Brand Name HIGH WOOD
Certification AS9001
Model Number 26KB02N
Minimum Order Quantity 100pcs
Price 10$-150$
Packaging Details Standard export package
Delivery Time 2-9weeks
Payment Terms T/T, L/C, Western Union
Supply Ability 100,000pcs per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Tensile Strength ≥68N (φ2mm Cable) Insertion Loss ≤0.5dB
Temperature -55℃~+125℃ Endurance 500 Cycles
Return Loss ≥20dB(850nm) Salt Spray Class K: 500h Class F: 48h Class W: 500h; Class MW: 192h (acidic Atmosphere)
Leave a Message
Product Description


The interface size conforms to GJB599B(MIL-DTL-38999)Ⅲ series, and the performance conforms to ARINC801 standard
Suitable for aeronautical, electronic, shipboard and other systems for multi-channel optical communication
Adopts standard 1.25mm ceramic pin for high docking accuracy
Ceramic casing package array, can be disassembled and replaced as a whole, easy to use and maintain
Install and remove tool M81969/14-03 for contact parts, easy to operate

How to order:

J599A6/26KB02N series optical fiber connector 0


Product pictures:

J599A6/26KB02N series optical fiber connector 1J599A6/26KB02N series optical fiber connector 2J599A6/26KB02N series optical fiber connector 3J599A6/26KB02N series optical fiber connector 4




Temperature :

-55℃ ~ +125

Salt spray:



Class MW: 192h (acidic atmosphere)

Air tightness (suitable for airtight switching socket): gas leakage rate ≤1×10-9Pa.m3/s, internal
and external pressure difference of 1 atmosphere


Tensile force:: ≥68N (2mm contact jumper)
Endurance: 500 cycles

10Hz ~ 2000Hz, powerspectral density 0.4G²/Hz, acceleration
root mean square value 23.1G

Impact: Peak acceleration 2940m/s²,duration 3ms,Velocity change rate5.61m/s


Optical performance​:

Insertion loss: ≤0.6dB
RL (return loss):   ≥ 20dB@850nm;
≥ 40dB@1310nm




Contact arrangement (take plug surface as an example):


                     J599A6/26KB02N series optical fiber connector 5
