Customized Rectangular Connector，HW-42TJL3-A
| Place of Origin | China |
|---|---|
| Brand Name | HIGHWOOD |
| Certification | AS9001 |
| Model Number | HW-42TJL3-A |
| Minimum Order Quantity | 100 pcs |
| Price | 10$-150$ |
| Packaging Details | Standard export package |
| Delivery Time | 2-9 weeks |
| Payment Terms | T/T, L/C, Western Union |
| Supply Ability | 100000 |
Product Details
| Ambient Temperature | -55℃ ~ +165℃ | Impact | 735m/s², 11ms |
|---|---|---|---|
| Shell | Aluminum Alloy Nickel Plated | Rated Current | 3A |
| Contact Resistance | ≤10mΩ | Insulation Resistance | ≥5000MΩ |
Product Description
HW-42TJL3-A
Product Introduction:
Rectangular customized connectors are electrical interconnection components deeply adapted for specific scenarios. By customizing the shell structure, contact layout, termination method and protection level, they ensure reliable transmission of power, signals and data, and are widely used in industrial automation, new energy, rail transit, medical and other fields.
Performance:
| Category | Parameter | Specification |
|---|---|---|
| Technical characteristics | Ambient temperature | -55℃ ~ +165℃ |
| Shock | 10Hz~2000Hz, 196m/s² | |
| Random vibration | Power spectral density 0.4G²/Hz
|
|
| Impact | 735m/s², 11ms | |
| Electrical performance indicators | Medium pressure resistance | 800V |
| Insulation resistance | ≥5000MΩ | |
| Contact resistance | ≤10mΩ | |
| Rated current | 3A | |
| Mechanical performance indicators | Mechanical life | 500 mating and unplugging times |
| Materials and coatings | Shell | Aluminum alloy nickel plated |
| Insulator | High quality engineering plastics | |
| Inner conductor |
Copper alloy gold plated, tail end tin plated
|
Product photo:
