Plug socket seal cover, 32F09R,D38999 Series Ⅲ.

  • Plug socket seal cover, 32F09R,D38999 Series Ⅲ.
  • Plug socket seal cover, 32F09R,D38999 Series Ⅲ.
  • Plug socket seal cover, 32F09R,D38999 Series Ⅲ.
  • Plug socket seal cover, 32F09R,D38999 Series Ⅲ.
  • Plug socket seal cover, 32F09R,D38999 Series Ⅲ.
Place of Origin China
Brand Name HIGH WOOD
Certification AS9001
Model Number 32F09R
Minimum Order Quantity 100pcs
Price 10$-150$
Packaging Details Standard export package
Delivery Time 2-9weeks
Payment Terms T/T, L/C, Western Union
Supply Ability 100，000pcs per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Type Of Connector Shielding Plug Contact Copper Alloy With Gold Plated
Type Of Contact SOCKET Insulator Thermo-set Plastic
Endurance 500 Cycles
Leave a Message
Product Description

(D38999/J599)32F09R

This series of round connectors, compliant with MIL-DTL-38999 III series requirements, adopt Triple-start threaded quick connection, with an anti-loose mechanism, featuring small size, light weight, high-density contacts, EMI/RFI shielding, removable crimp contacts, and anti oblique-mating;

This product has a fireproof shell, a variety of coatings, and vibration performance of high strength under high temperature, suitable for use in harsh sandstorm and damp circumstances.the material of shell is optional in aluminum-alloy, naval brass, stainless steel or composite.



How to order:

Plug socket seal cover, 32F09R,D38999 Series Ⅲ. 0







Product pictures:

Plug socket seal cover, 32F09R,D38999 Series Ⅲ. 1Plug socket seal cover, 32F09R,D38999 Series Ⅲ. 2Plug socket seal cover, 32F09R,D38999 Series Ⅲ. 3Plug socket seal cover, 32F09R,D38999 Series Ⅲ. 4



Dimensions:



Shell no. 09 11 13 15 17 19 21 23 25
A 22.5 26.5 29.5 32.5 36 38.4 41.7 44.4 48.3
B min 12.92 17.78 19.27 22.6 25.62 28.95 31.97 34.03 38.32
C 22.5 26.5 29.5 32.5 36 38.4 41.7 44.4 48.3
D min 17.78 21.33 25.62 28.95 31.97 35.3 38.32 41.65 44.45





Plug socket seal cover, 32F09R,D38999 Series Ⅲ. 5
