Plug socket seal cover, 33F15R,D38999 Series Ⅲ.
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xType Of Connector | Shielding Plug | Contact | Copper Alloy With Gold Plated |
---|---|---|---|
Type Of Contact | SOCKET | Insulator | Thermo-set Plastic |
Endurance | 500 Cycles |
(D38999/J599)33F15R
This series of round connectors, compliant with MIL-DTL-38999 III series requirements, adopt Triple-start threaded quick connection, with an anti-loose mechanism, featuring small size, light weight, high-density contacts, EMI/RFI shielding, removable crimp contacts, and anti oblique-mating;
This product has a fireproof shell, a variety of coatings, and vibration performance of high strength under high temperature, suitable for use in harsh sandstorm and damp circumstances.the material of shell is optional in aluminum-alloy, naval brass, stainless steel or composite.
How to order:
Product pictures:
Dimensions:
Shell no. | 09 | 11 | 13 | 15 | 17 | 19 | 21 | 23 | 25 |
A | 22.5 | 26.5 | 29.5 | 32.5 | 36 | 38.4 | 41.7 | 44.4 | 48.3 |
B min | 12.92 | 17.78 | 19.27 | 22.6 | 25.62 | 28.95 | 31.97 | 34.03 | 38.32 |
C | 22.5 | 26.5 | 29.5 | 32.5 | 36 | 38.4 | 41.7 | 44.4 | 48.3 |
D min | 17.78 | 21.33 | 25.62 | 28.95 | 31.97 | 35.3 | 38.32 | 41.65 | 44.45 |
