Tail accessories (suitable for GJB599 III series connectors),J1784A/38-17W.

Place of Origin China
Brand Name HIGH WOOD
Certification AS9001
Model Number J1784A/38-17W
Minimum Order Quantity 100pcs
Price 10$-150$
Packaging Details Standard export package
Delivery Time 2-9weeks
Payment Terms T/T, L/C, Western Union
Supply Ability 100,000pcs per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Type Of Connector Shielding Plug Contact Copper Alloy With Gold Plated
Plating Olive Green Cadmium Plating Type Of Contact Crimp Socket
Insulator Thermo-set Plastic Endurance 500 Cycles
Leave a Message
Product Description

J1784A/38-17W



This type of attachment complies with the national military standard GJB1784 (equivalent to the US military standard MIL-C-85049).

Note: 1. The reference to "J1784" in the attachment model is equivalent to "J1784A" without distinction.

2. When using attachments, at least one of the following anti loosening measures should be taken:

① Thread the fuse through the safety hole to prevent loosening;

② Apply thread sealant to the tail thread of the product and tighten the connecting nut to prevent loosening;

③ Use a heat shrink tube to shrink the entire accessory to prevent loosening.

3. Accessories with set screws should be coated with thread sealant before tightening them.

4. If the product that the cable accessory is suitable for is equipped with contact 8, it is necessary to choose a longer cable accessory such as J1784/38H or J1784/18 to avoid interference between the contact locator and the cable accessory.





How to order:

Tail accessories (suitable for GJB599 III series connectors),J1784A/38-17W. 0





Product pictures:



Tail accessories (suitable for GJB599 III series connectors),J1784A/38-17W. 1Tail accessories (suitable for GJB599 III series connectors),J1784A/38-17W. 2Tail accessories (suitable for GJB599 III series connectors),J1784A/38-17W. 3Tail accessories (suitable for GJB599 III series connectors),J1784A/38-17W. 4





Example of model marking:



J1784/38-09S, series main name J1784, type 38- straight cable clamp (clamp cable unshielded accessory),

accessory housing number 09, shell plating is stainless steel passivation.





J1784/38 straight cable clamp (clamp cable unshielded accessory)

Tail accessories (suitable for GJB599 III series connectors),J1784A/38-17W. 5
