HW-CMM Connector , HW-222Y06M16 , 2mm Pitch

  • HW-CMM Connector , HW-222Y06M16 , 2mm Pitch
  • HW-CMM Connector , HW-222Y06M16 , 2mm Pitch
  • HW-CMM Connector , HW-222Y06M16 , 2mm Pitch
  • HW-CMM Connector , HW-222Y06M16 , 2mm Pitch
  • HW-CMM Connector , HW-222Y06M16 , 2mm Pitch
Place of Origin China
Brand Name HIGH WOOD
Certification AS9001
Model Number HW-222Y06M16
Minimum Order Quantity 100PCS
Price 10＄--150＄
Packaging Details standard export package
Delivery Time 2--9 weeks
Payment Terms L/C, T/T, Western Union
Supply Ability 100,000pcs per month
Product Details
CRIMP LF CONTACTS Male: Body:copper Alloy/Ni+Au>1µ Female: Body:copper Alloy/Ni+Au 0,2 µ Socket:berylliumcopper/Ni+Au>1,25 µ P.C.LF CONTACTS(Male) Male:tail:copper Alloy/Ni+Au Flash 0,1µContact Area:copper Alloy/Ni+Au>1 µ
P.C.LF CONTACTS(Female) Body:copper Alloy/Ni+Au 0,2 µ Socket:berylliumcopper/Ni+Au>1,25 µ FIXING HARDARE Jackscrew:Stainless Steel Latch:Bertllium Copper/plated Nickel
INSULATOR Special PPS UL 94-V0 MECHANICAL Mechanical Operations:Up To 2500 Cycles Contact Inssertion And Withdrawal Force:2 N Max./0.2n Min.oer Ciontact Contact Retention In Insulator:10 N Min Contact Replacement In Insulator:3 Cycles
Highlight

HW-CMM 2mm pitch connector

,

HW-222Y06M16 Micron-D connector

,

HW-M80 2mm pitch connector
Leave a Message
Product Description

HW-222Y06M16


The HW-CMM has been developed for the aerospace,avionics,instrumentation & control,defence and transportation markets,with applications that induce IFES,HUDs,fight controls,FADEC units,radars,missiles, electro-optical sighting systems,satellites,mobile radios,power supplies,UAVs and engine controls.It is also used engine controls.It is also used in a growing number of medical,and telecom applications, pecializes in the design,development and manufacture of electronic connectors.



Materials and coating:

Materials and coating
Insulating medium

Glass fiber reinforced PPS, UL94-V0

Radiation resistant, non hygroscopic, ozone resistant
Contact Copper alloy nickel base plating
Enclosure stainless steel
Electrical performance index
Voltage withstand test (sea level) 800V AC/DC
Insulation resistance ≥1000MΩ
Rated current

LF contact: working current 25 C, ≤ 3A;

Working current 85 C, ≤ 2.2A; contact resistance ≤10mΩ
Mechanical performance index
Mechanical life 500 times of plugging and unplugging
Environmental performance index
Operating ambient temperature -60℃ to 260℃



1. The contacts are distributed, and it is recommended to crimp the AWG22 wire for LF contacts;

2. After LF contact is pressed into the base with special tools, it is recommended to use the heat shrinkable sleeve

shrinks

its tail and fills the base cavity with glue;



Product details:



HW-CMM Connector , HW-222Y06M16 , 2mm Pitch 0HW-CMM Connector , HW-222Y06M16 , 2mm Pitch 1HW-CMM Connector , HW-222Y06M16 , 2mm Pitch 2HW-CMM Connector , HW-222Y06M16 , 2mm Pitch 3
