HW-CMM Connectors,HW-322C021H01
| Place of Origin | China |
|---|---|
| Brand Name | HIGH WOOD |
| Certification | AS9001 |
| Model Number | HW-322C021H01 |
| Minimum Order Quantity | 100PCS |
| Price | 10＄--150＄ |
| Packaging Details | Details standard export package |
| Delivery Time | 2--9 weeks |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 100,000pcs per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| MECHANICAL | Up To 2500 Cycles Contact Inssertion And Withdrawal Force:2 N Max./0.2n Min.oer Ciontact Contact Retention In Insulator:10 N Min Contact Replacement In Insulator:3 Cycles | FIXING HARDARE | Stainless Steel Latch:Bertllium Copper/plated Nickel |
|---|---|---|---|
| P.C.LF CONTACTS(Female) | Copper Alloy/Ni+Au 0,2 µ Socket:berylliumcopper/Ni+Au>1,25 µ | CRIMP LF CONTACTS | Body:copper Alloy/Ni+Au>1µ Female: Body:copper Alloy/Ni+Au 0,2 µ Socket:berylliumcopper/Ni+Au>1,25 µ |
| P.C.LF CONTACTS(Male) | Tail:copper Alloy/Ni+Au Flash 0,1µContact Area:copper Alloy/Ni+Au>1 µ | INSULATOR | Special PPS UL 94-V0 |
Product Description
HW-322C021H01
The CMM has been developed for the aerospace,avionics,instrumentation & control,defence and transportation markets,with applications that induce IFES,HUDs,fight controls,FADEC units,radars,missiles, electro-optical sighting systems,satellites,mobile radios,power supplies,UAVs and engine controls.It is also used engine controls.It is also used in a growing number of medical,and telecom applications,The CMM MICRO CONNECTOR interconnection system is a 2mm pitch connector (square matrix) witch proven high.
Part numbering:
RACK INTERCONNECTION:
| Male connectors cmm series 320&340 rack | ||||||||||||||||||||||||||
| Type of contact in connetor PCB contacts contacts on cable | ||||||||||||||||||||||||||
| Type of PCB mount straight 90° straight 90° | ||||||||||||||||||||||||||
| PCB chickness(mm) |
0.8min 2max |
1.5min 4max |
0.8min 2max |
1.5min 4max |
4max |
0.8min 2max |
1,5min4max | 4max | Floation |
No fixing on pcb
|
||||||||||||||||
| Fixing M38 M38H M36 M36H F58 F58H F59 F59H F48 H11 M35 M39 F48 H11 M3xx F40 | ||||||||||||||||||||||||||
| 0.8 min |
M35
|
Ok
|
Ok
|
Ok
|
Ok
|
Ok
|
Ok
|
Ok
|
||||||||||||||||||
| 2max | M35H | OK | OK | OK | OK | OK | OK | OK | ||||||||||||||||||
| straight |
1.5min
|
M39
|
Ok
|
Ok
|
Ok
|
Ok
|
Ok
|
OK
|
OK
|
|||||||||||||||||
| 4max | M39h | OK | OK | OK | OK | OK | OK | OK | ||||||||||||||||||
| 90° | 4max |
H11
|
|
|
|
|
OK | OK | OK | OK | A |
|
|
|
A |
|
|
OK |
||||||||
| F48 | OK | OK | OK | OK | A | OK | OK | A | OK | |||||||||||||||||
|
No fixing On PCB |
F40 | OK | OK | OK | OK | OK | OK | OK | OK | OK | ||||||||||||||||
| Straight |
0.8min 2max |
M35
|
OK | OK | OK | OK | OK | OK | OK | |||||||||||||||||
|
1.5min 4max |
M39 | OK | OK | OK | OK | OK | OK | OK | ||||||||||||||||||
| 90° | 4max |
H11
|
|
|
|
|
OK | OK | OK | OK | A | A |
|
|
||||||||||||
| F48 | OK | OK | OK | OK | A | OK | OK | A | OK | |||||||||||||||||
| floating | M3xx | OK | OK | OK | OK | OK | OK | OK | ||||||||||||||||||
|
NO fixing On PCB |
No fixing on PCB | F40 | OK | OK | OK | OK | OK | OK | OK | OK | OK | |||||||||||||||
|
REFERENCE
|
ASSEMBLY ON PCB
|
OVERALL DIMENSIONS
|
RECOMMENDATION
|
|
H01 H01C |
|
|
H01/H01C : CMM female : Y-YL-S-C-E (D : straight) CMM male : Y-YL-S-C-E (D : straight)
|
Product showing.
