HW-M83-LFT2FHN96-0000-000 3-Row Datamate Connectors
| Place of Origin | China |
|---|---|
| Brand Name | HIGH WOOD |
| Certification | AS9001 |
| Model Number | HW-M83-LFT2FHN96-0000-000 |
| Minimum Order Quantity | 100PCS |
| Price | 10＄--150＄ |
| Packaging Details | standard export package |
| Delivery Time | 2--9 weeks |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 100,000pcs per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Insulation Resistance | ≥1000MΩ | Insulator | Glass Fiber Reinforced PPS |
|---|---|---|---|
| Accessory | Stainless Steel | Endurance | 500cycles |
| Operating Temperature | -55 ℃ - 125 ℃ | Contact | Copper Alloy Nickel Bottom Gold Plating |
| Highlight | HW-M83-LFT2FHN96-0000-000,3 Row Datamate Connectors,HW-M83 Datamate Connectors |
||
Product Description
HW-M83-LFT2FHN96-0000-000
M83 3-Row Datamate Connectors offer high reliability with a space-saving design. Available in six standard sizes from 18 to 96 contacts, the 2mm pitch, 3A per contact connectors are ideal for board-to-board or cable-to-board applications where a high number of contacts are required in a small space. The 3-Row Datamate Connectors are available with vertical or horizontal PCB tails and all contacts are gold finish. Applications include Industrial, Medical and Military/Aerospace markets.
Specification:
- Materials
- Glass-filled thermoplastic moldings, UL94V-0
- Brass shell female contacts with beryllium copper inner contact
- Phosphor bronze male contacts
- Gold finish
- Mechanical
- 500 operation durability
- 1.0N maximum insertion force
- 0.2N minimum withdrawal force
- Environmental
- -55°C to +125°C operating temperature range
- Electrical
- 2.2A to 3.3A current range
- 800VDC/ACrms working voltage
- 1200VDC/ACrms voltage proof
- 20mΩ to 25mΩ maximum contact resistance
FEATURES
- Increased contact count with low insertion force contacts
- High levels of shock and vibration
- High-reliability applications
Product pictures:
