HW-M80 Connectors, HW-M80-5400805 2mm pitch electric connector

Place of Origin China
Brand Name HIGH WOOD
Certification AS9001
Model Number HW-M80-5400805
Minimum Order Quantity 100PCS
Price 10$--150$
Packaging Details standard export package
Delivery Time 2--9 weeks
Payment Terms L/C, T/T, Western Union
Supply Ability 100,000pcs per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Insulation Resistance ≥1000MΩ Insulator Glass Fiber Reinforced PPS
Accessory Stainless Steel Endurance 500cycles
Operating Temperature -55 ℃ - 125 ℃ Contact Copper Alloy Nickel Bottom Gold Plating
Leave a Message
Product Description

HW-M80-5400805

The HW-M80-series conectors has been developed for the aerospace,avionics,instrumentation & control,defence and transportation markets,with applications that induce IFES,HUDs,fight controls,FADEC units,radars,missiles, electro-optical sighting systems,satellites,mobile radios,power supplies,UAVs and engine controls.It is also used engine controls.It is also used in a growing number of medical,and telecom applications, pecializes in the design,development and manufacture of electronic connectors.



 Specification:

Material and coating
Insulating medium Glass fiber reinforced PPS,UL94-V0 is radiation resistant, non-moisture absorbing and ozone resistant
Contact LF contact:
Copper alloy nickel base gold plating
Attachment Stainless steel
Electrical performance index
Pressure resistance (sea level) 1200V AC/DC
Insulation Resistance ≥1000MΩ
Contact LF contact: working current 25℃≤3A; Working current 85℃, ≤2.2A; Contact resistance ≤10mΩ
Mechanical performance index
Mechanical life 500 cycles
Environmental performance index
Working Temperature -55 ℃ to 125 ℃



Product details:

HW-M80 Connectors, HW-M80-5400805 2mm pitch electric connector 0

HW-M80 Connectors, HW-M80-5400805 2mm pitch electric connector 1HW-M80 Connectors, HW-M80-5400805 2mm pitch electric connector 2

HW-M80 Connectors, HW-M80-5400805 2mm pitch electric connector 3





Product pictures:

 HW-M80 Connectors, HW-M80-5400805 2mm pitch electric connector 4HW-M80 Connectors, HW-M80-5400805 2mm pitch electric connector 5HW-M80 Connectors, HW-M80-5400805 2mm pitch electric connector 6HW-M80 Connectors, HW-M80-5400805 2mm pitch electric connector 7
