CMM Series Connectors, HW-222Y20M12 With Special PPS Insulator

  • CMM Series Connectors, HW-222Y20M12 With Special PPS Insulator
  • CMM Series Connectors, HW-222Y20M12 With Special PPS Insulator
  • CMM Series Connectors, HW-222Y20M12 With Special PPS Insulator
  • CMM Series Connectors, HW-222Y20M12 With Special PPS Insulator
Place of Origin China
Brand Name HIGH WOOD
Certification AS9001
Model Number HW-222Y20M12
Minimum Order Quantity 100PCS
Price 10＄--150＄
Packaging Details standard export package
Delivery Time 2--9 weeks
Payment Terms L/C, T/T, Western Union
Supply Ability 100,000pcs per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Resistance To Insulation ≥1000MΩ Insulators PPS+glass Fiber
Accessory Stainless Steel Endurance 500cycles
Operating Temperature -55 ℃ - 125 ℃ Contact Copper Alloy Nickel Base Gold Plating
High Light

HW-222Y20M12

,

PPS Insulator CMM Series Connectors
Leave a Message
Product Description

HW-222Y20M12

The HW-222Y20M12 has been developed for the aerospace,avionics,instrumentation & control,defence and transportation markets,with applications that induce IFES,HUDs,fight controls,FADEC units,radars,missiles, electro-optical sighting systems,satellites,mobile radios,power supplies,UAVs and engine controls.It is also used engine controls.It is also used in a growing number of medical,and telecom applications, pecializes in the design,development and manufacture of electronic connectors.



Product pictures:



CMM Series Connectors, HW-222Y20M12 With Special PPS Insulator 0CMM Series Connectors, HW-222Y20M12 With Special PPS Insulator 1CMM Series Connectors, HW-222Y20M12 With Special PPS Insulator 2



SPECIFICATIONS:

TECHNICALS FEATURES
MATERIAL INSULATOR : Special PPS
FIXING HARDWARE Jackscrew : Stainless steel
ELECTRICAL for LF Contacts
All contacts 3 A max. @ 25°C
2.2 A max. @ 85°C
Working voltage (sea level) Tested at 800 V DC
Proof voltage Tested at 1200 V DC
Contact resistance (initially) max. 10 mΩ
Insulation resistance 1000 MΩ min
MECHANICAL for LF Contacts
Mechanical operations 500 cycles min. up to 2500
Contact insertion and withdrawal force 2 N max. / 0.2 N min.
ENVIRONMENTAL
Temperature range From -60°C to +260°C
