HW-CMM Connector , HW-322C051H01

  • HW-CMM Connector , HW-322C051H01
  • HW-CMM Connector , HW-322C051H01
  • HW-CMM Connector , HW-322C051H01
  • HW-CMM Connector , HW-322C051H01
  • HW-CMM Connector , HW-322C051H01
Place of Origin China
Brand Name HIGH WOOD
Certification AS9001
Model Number HW-322C051H01
Minimum Order Quantity 100PCS
Price 10＄--150＄
Packaging Details standard export package
Delivery Time 2--9 weeks
Payment Terms L/C, T/T, Western Union
Supply Ability 100,000pcs per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
CRIMP LF CONTACTS Male: Body:copper Alloy/Ni+Au>1µ Female: Body:copper Alloy/Ni+Au 0,2 µ Socket:berylliumcopper/Ni+Au>1,25 µ FIXING HARDARE Jackscrew:Stainless Steel Latch:Bertllium Copper/plated Nickel
MECHANICAL Mechanical Operations:Up To 2500 Cycles Contact Inssertion And Withdrawal Force:2 N Max./0.2n Min.oer Ciontact Contact Retention In Insulator:10 N Min Contact Replacement In Insulator:3 Cycles P.C.LF CONTACTS(Female) Body:copper Alloy/Ni+Au 0,2 µ Socket:berylliumcopper/Ni+Au>1,25 µ
INSULATOR Special PPS UL 94-V0 P.C.LF CONTACTS(Male) Male:tail:copper Alloy/Ni+Au Flash 0,1µContact Area:copper Alloy/Ni+Au>1 µ
High Light

HW-322C051H01

,

Aerospace HW-CMM Connector
Leave a Message
Product Description

HW-322C051H01

The CMM has been developed for the aerospace,avionics,instrumentation & control,defence and transportation markets,with applications that induce IFES,HUDs,fight controls,FADEC units,radars,missiles, electro-optical sighting systems,satellites,mobile radios,power supplies,UAVs and engine controls.It is also used engine controls.It is also used in a growing number of medical,and telecom applications,The CMM MICRO CONNECTOR interconnection system is a 2mm pitch connector (square matrix) witch proven high.


 Part numbering:

HW-CMM Connector , HW-322C051H01 0





CMM 320/340 MALE AND FEMALE THREADED FIXING HARDWARE


REFERENCE



ASSEMBLY ON PCB



OVERALL DIMENSIONS



RECOMMENDATION



HW-CMM Connector , HW-322C051H01 1



HW-CMM Connector , HW-322C051H01 2

 HW-CMM Connector , HW-322C051H01 3

H01/H01C :

CMM female :

Y-YL-S-C-E (D : straight)

CMM male :

Y-YL-S-C-E (D : straight)



H08 PCB :

1 min. / 2 max.

H08M PCB :

2 min. / 3 max.

H08L PCB :

3 min. / 4 max



 HW-CMM Connector , HW-322C051H01 4 HW-CMM Connector , HW-322C051H01 5

H08/H08M/H08L :

CMM female :

V-VL-S-C-E (D : 90°)

CMM male :

V-VL-R-S-C-E (D : 90°)









Product showing:

HW-CMM Connector , HW-322C051H01 6HW-CMM Connector , HW-322C051H01 7HW-CMM Connector , HW-322C051H01 8HW-CMM Connector , HW-322C051H01 9
