HW-CMM Connector , HW-322C045H01

Place of Origin China
Brand Name HIGH WOOD
Certification AS9001
Model Number HW-322C045H01
Minimum Order Quantity 100PCS
Price 10$--150$
Packaging Details standard export package
Delivery Time 2--9 weeks
Payment Terms L/C, T/T, Western Union
Supply Ability 100,000pcs per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
CRIMP LF CONTACTS Male: Body:copper Alloy/Ni+Au>1µ Female: Body:copper Alloy/Ni+Au 0,2 µ Socket:berylliumcopper/Ni+Au>1,25 µ FIXING HARDARE Jackscrew:Stainless Steel Latch:Bertllium Copper/plated Nickel
MECHANICAL Mechanical Operations:Up To 2500 Cycles Contact Inssertion And Withdrawal Force:2 N Max./0.2n Min.oer Ciontact Contact Retention In Insulator:10 N Min Contact Replacement In Insulator:3 Cycles P.C.LF CONTACTS(Female) Body:copper Alloy/Ni+Au 0,2 µ Socket:berylliumcopper/Ni+Au>1,25 µ
INSULATOR Special PPS UL 94-V0 P.C.LF CONTACTS(Male) Male:tail:copper Alloy/Ni+Au Flash 0,1µContact Area:copper Alloy/Ni+Au>1 µ
High Light

HUDs HW-CMM Connector

,

HW-322C045H01

Leave a Message
Product Description

HW-322C045H01

The CMM has been developed for the aerospace,avionics,instrumentation & control,defence and transportation markets,with applications that induce IFES,HUDs,fight controls,FADEC units,radars,missiles, electro-optical sighting systems,satellites,mobile radios,power supplies,UAVs and engine controls.It is also used engine controls.It is also used in a growing number of medical,and telecom applications,The CMM MICRO CONNECTOR interconnection system is a 2mm pitch connector (square matrix) witch proven high.


 Part numbering:

HW-CMM Connector , HW-322C045H01 0





Fixing for CMM 320

HW-CMM Connector , HW-322C045H01 1







Product showing:

HW-CMM Connector , HW-322C045H01 2HW-CMM Connector , HW-322C045H01 3HW-CMM Connector , HW-322C045H01 4HW-CMM Connector , HW-322C045H01 5HW-CMM Connector , HW-322C045H01 2HW-CMM Connector , HW-322C045H01 3HW-CMM Connector , HW-322C045H01 4HW-CMM Connector , HW-322C045H01 5
