HW-EMM Connectors,HW-E221Y36E01.
| Place of Origin | China |
|---|---|
| Brand Name | HIGH WOOD |
| Certification | AS9001 |
| Model Number | HW-E221Y36E01 |
| Minimum Order Quantity | 100PCS |
| Price | 10＄--150＄ |
| Packaging Details | Details standard export package |
| Delivery Time | 2--9 weeks |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 100,000pcs per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Fungus Resistance | 28 Days/29°C/HR 90%/ TCA DO 160G | Dielectric Withstanding Voltage Sea Level | Dielectric Withstanding Voltage @sea Level: 600 V RMS. Connectors Shall Show No Evidence Of Breakdown Or Flashover |
|---|---|---|---|
| Insulation Resistance | > 2000 GΩ@ 500V | Low Level Contact Resistance | Less Than 9 MΩ |
| Contact Resistance | Less Than 8 MΩ | Contact Current Capability (derating) | Configuration Y/Y: 3,4A @25°C And 2,5A @85°C Confiiguration Y/V: 3,9A @25°C And 2,5A @85°C |
Product Description
HW-E221Y36E01
EMM ACHIEVES EXTRA SPACE AND WEIGHT REDUCTION TO MEET YOUR MINIATURIZATION NEEDS IN THE MOST EXTREME ENVIRONMENTS
Designed to meet the performance requirements of MIL 83513-G, the range combines rugged design with enhanced electrical and environmental performances
SPACE SAVING:Easy installation thanks to a perfect balance between the pitch and the overall dimensions of the range.
REVERSED CONTACTS:Male contacts, thinner by essence, are protected inside the insulator.
HIGH MODULARITY:Straight male and female thru-hole and SMT 90° male and female thru-hole and male SMT Cable AWG 24-30 04 to 60 pins.
90° BACK PROTECTION:Featured exclusively on 90° connectors mount, contacts are protected at the back by an ingenious shape, also guaranteeing a perfect alignment of the contacts.
HARNESS
Mounted on the connector Torque 0.2 Nm
Product showing.
