Aptiv Metri-Pack 280 Series Automotive Connectors HW280-028P4H62MTNNA

Place of Origin China
Brand Name HIGH WOOD
Certification AS9001
Model Number HW280-028P4H62MTNNA
Minimum Order Quantity 100pcs
Price 10$-150$
Packaging Details Standard export package
Delivery Time 2-9weeks
Payment Terms T/T, L/C, Western Union
Supply Ability 50,000pcs per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Shell Material PPS+fiberglass Withstand Voltage 1000V AC
Insulation Resistance ≥5000MΩ Rated Current 5A
Vibration Random,power Spectral Density 43.92G Impact 300G
Temperature -65℃~+200℃ Waterproof IP67
Highlight

PPS Fiberglass Automotive Connectors

,

HW280-028P4H62MTNNA

Leave a Message
Product Description

HW280-028P4H62MTNNA

Low profile right angle PC tail HiPer-D® pin connectors feature rugged machined aluminum shell and stainless steel cover for improved EMI protection. Contacts are non-removable, size #20 or #22. Intermateable with standard M24308-type D-Subminiature connectors, the HiPer-D® features a resilient face seal for environmental protection and optional ground springs for improved resistance to electromagnetic interference. Threaded holes on the bottom of the connector allow attachment to circuit board. Contacts are potted with epoxy. Glass-reinforced thermoset epoxy insulators, fluorosilicone face seal. 1000 VAC, 5 Amps (#22) or 7.5 Amps (#20).



How to order:

HW 280-028P 4H62 ME G N A
Basic Part Number

HW280-028P





Shell Size

Contact Arrangement

See Shell Size - Contact Arrangements Table
Shell Finish

ME = Electroless Nickel                      MT = Nickel-PTFE

JF = Cadmium with Yellow Chromate Z2 = Gold

Z1 = Passivated Stainless Steel

Ground Spring



G = Supplied with EMI Ground Spring

N = No Ground Spring

Mating Hardware



N = No Hardware (supplied with #4-40 tapped holes)

P = #4-40 Female Jackposts

PC Tail Length A = .125 (3.18) Tail Length B = .250 (6.35) Tail Length



Product pictures:



Aptiv Metri-Pack 280 Series Automotive Connectors HW280-028P4H62MTNNA 0

Aptiv Metri-Pack 280 Series Automotive Connectors HW280-028P4H62MTNNA 1Aptiv Metri-Pack 280 Series Automotive Connectors HW280-028P4H62MTNNA 2Aptiv Metri-Pack 280 Series Automotive Connectors HW280-028P4H62MTNNA 3



Shell Size - Contact Arrangements:

Shell Size- Contact Arr. Contact Size and Qty
#20 #22
                                    Standard Density
1S9 9
2S15 15
3S25 25
4S37 37
5S50 50
                               High Density
1H15   15
2H26   26
3H44   44
4H62   62
5H78   78
6H104   104





Materials and Finishes:

Shell Aluminum alloy
Contacts Copper alloy, 50 microin. gold plated
Insulators Thermoset epoxy
Potting Compound Epoxy
Interfacial Seal Fluorosilicone rubber
Hardware 300 series stainless steel





Specifications:

Current Rating #22 5 AMPS, #20 7.5 AMPS
Test Voltage 1000 VAC RMS
Insulation Resistance 5000 megohms minimum
Operating Temperature -65° C. to +200° C.
Ingress Protection IP 67
Shock 300 g.
Vibration, Random 43.92 g.



Shell Size:

Shell Size

A B C Basic D E

in

± .015

mm

± 0.38

in

± .015

mm

± 0.38



in.



mm

in

± .005

mm

± 0.13

in

± .005

mm

± 0.13

1 1.213 30.81 .494 12.55 .984 24.99 .726 18.44 .389 9.88
2 1.541 39.14 .494 12.55 1.312 33.32 1.054 26.77 .389 9.88
3 2.088 53.04 .494 12.55 1.852 47.04 1.594 40.49 .389 9.88
4 2.729 69.32 .494 12.55 2.500 63.50 2.242 56.95 .389 9.88
5 2.635 66.93 .605 15.37 2.406 61.11 2.139 54.33 .501 12.73
6 2.729 69.32 .668 16.97 2.500 63.50 2.272 57.71 .563 14.30
