MICRO-D Rectangular Connectors , CRM-232-010-111-8402
| Place of Origin | China |
|---|---|
| Brand Name | HIGH WOOD |
| Certification | AS9001 |
| Model Number | CRM-232-010-111-8402 |
| Minimum Order Quantity | 100PCS |
| Price | 10＄--150＄ |
| Packaging Details | standard export package |
| Delivery Time | 2--9 weeks |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 100,000pcs per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Operating Temperature | -55℃~+125℃ | Rated Current | 3A |
|---|---|---|---|
| Mating Times | 1000 Cycle | Contact Resistance | ≤25mΩ |
| Impact | Acceleration 980m/s 2 | Locking Attachment | Stainless Steel |
| Insulator | PPS | Inner Conductor | The Copper Alloy Is Plated With Gold |
Product Description
CRM SERIES MICRO-D Rectangular Connectors, CRM-232-010-111-8402
THE CRM SERIES CONNECTOR FEATURES:
|
Technical characteristics
|
|
|
Ambient temperature
|
-55℃~+125℃
|
|
Vibration
|
10Hz~2000Hz 147m/s 2
|
|
Impact
|
Acceleration 980m/s 2 |
|
Electrical performance index
|
|
|
Dielectric withstand voltage
|
750V(Standard atmosphere) 250V(Low atmospheric pressure)
|
|
Insulation resistance
|
≥5000MΩ(Normal temperature) ≥20MΩ (Damp and hot)
|
|
Contact resistance
|
≤25mΩ
|
|
Rated current
|
3A |
|
Mechanical performance index
|
|
|
Mechanical life
|
1000 times |
|
Material and coating
|
|
|
Locking attachment
|
Stainless steel |
| Insulator | PPS |
| Inner conductor | The copper alloy is plated with gold |
Product show:
Drawings show:
