P Series P16K4P Circular Electrical Connectors Mainly Adopt Russian Connector Technology

  • P Series P16K4P Circular Electrical Connectors Mainly Adopt Russian Connector Technology
  • P Series P16K4P Circular Electrical Connectors Mainly Adopt Russian Connector Technology
  • P Series P16K4P Circular Electrical Connectors Mainly Adopt Russian Connector Technology
  • P Series P16K4P Circular Electrical Connectors Mainly Adopt Russian Connector Technology
Place of Origin China
Brand Name HIGH WOOD
Certification AS9001
Model Number P16K4P
Minimum Order Quantity 100pcs
Price 10$-150$
Packaging Details Standard export package
Delivery Time 2-9weeks
Payment Terms T/T, L/C, Western Union
Supply Ability 100，000pcs per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Impact Acceleration Once 500g， Multiple Times 35g Withstanding Voltage 1500VAC
Contact Materia Copper With Silver/gold Plated Working Life 500 Times Plugging, 1000 Hours
Operating Temperature -60℃ - 50℃ Connection Method Thread Connection
Highlight

P16K4P Circular Electrical Connectors

,

P Series Circular Electrical Connectors
Leave a Message
Product Description

P16K4P  circular electrical connectors



Product introduction

P series
Ordinary circular electrical connectors are standard electrical connectors, sealed and unsealed types. The connector generally
consists of a part fixed on the instrument (receptacle) and a part fixed Nessesory For Unclean  environment (only plug)
on the cable (plug), connected by means of a coupling nut.

Product pictures:
P Series P16K4P Circular Electrical Connectors Mainly Adopt Russian Connector Technology 0P Series P16K4P Circular Electrical Connectors Mainly Adopt Russian Connector Technology 1P Series P16K4P Circular Electrical Connectors Mainly Adopt Russian Connector Technology 2P Series P16K4P Circular Electrical Connectors Mainly Adopt Russian Connector Technology 3


How to order:



P Series P16K4P Circular Electrical Connectors Mainly Adopt Russian Connector Technology 4



P Series P16K4P Circular Electrical Connectors Mainly Adopt Russian Connector Technology 5





Technical Performance

Operating temperature: -60℃ ~+50℃
Vibration acceleration:10G(P 5~2000hz)
Impact acceleration:once 500g, multiple times 35g
Operating voltage:≤850V
Withstanding voltage:1500VAC
Working life: 500 times plugging, 1000 hours

Rated current:

Φ1.5 Φ2.5 Φ3.5 Φ5.5

Φ9
10A 25A 50A 100A 200A



Contact resistance:



Φ1.5 Φ2.5 Φ3.5 Φ5.5 Φ9
2.5mΩ 1mΩ 0.5mΩ 0.3mΩ 0.15mΩ
