2PM Series 2PM27K7QB1 Circular Electrical Connectors Straight Cable Plug

  • 2PM Series 2PM27K7QB1 Circular Electrical Connectors Straight Cable Plug
  • 2PM Series 2PM27K7QB1 Circular Electrical Connectors Straight Cable Plug
  • 2PM Series 2PM27K7QB1 Circular Electrical Connectors Straight Cable Plug
  • 2PM Series 2PM27K7QB1 Circular Electrical Connectors Straight Cable Plug
Place of Origin China
Brand Name HIGH WOOD
Certification AS9001
Model Number 2PM27K7QB1
Minimum Order Quantity 100pcs
Price 10$-150$
Packaging Details Standard export package
Delivery Time 2-9weeks
Payment Terms T/T, L/C, Western Union
Supply Ability 100，000pcs per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Connector Type Cable Plug /panel Socket Orentation Straight/Angled
Connection Method Thread Connection Shell Material Aluminum Alloy
Contact Materia Copper With Silver/gold Plated Termination Solder
Mating Cycles 500 Times Operating Temperature -60℃ - +200℃
Highlight

2PM27K7QB1 Circular Electrical Connectors

,

Gold Plated Circular Electrical Connectors

,

Straight cable plug Circular Electrical Connectors
Leave a Message
Product Description

2PM series 2PM27K7QB1 circular electrical connectors



Product introduction

2PM series
circular electrical connectors mainly adopt Russian connector
technology.It is widely used for electrical connection and signal transmission
between electrical equipment in railway system,trams and trolley bus etc.
Its unique structure can make up for the shortcomings of many other similar
connectors,making it more convenient and scientific to use.
The cable plug and panel socket are threaded connection.
The panel socket also has a glass sintered sealed socket (M) and a glass sintered sealed bulkhead socket (C),which can
simultaneously meet the user equirements inspecial environments such as vacuum,sealing,and high temperature.It can be
matched and interchanged with original parts of Russian2PM(T) /2РМД(T) ,2РМГ/2РМГД,2РМГП/2РМГПД series



2PM Series 2PM27K7QB1 Circular Electrical Connectors Straight Cable Plug 0



   HIGH WOOD P/N

2PM Series 2PM27K7QB1 Circular Electrical Connectors Straight Cable Plug 1



Technical Performance

Connector type: Cable plug /panel socket
Orentation: Straight/Angled
Connection method: Thread connection
Shell Material: Aluminum alloy
Contact Material: Copper with silver/gold plated
Shell Size: 2PM14/18/22/24/27/30/33/36/39/42/45
Contacts: 4/7/8/10/19/20/22/24/32/45/50
Termination: Solder
Mating Cycles: 500 times
Working Voltage: ≤700V
Working Current: 5-40A
Insulater: Bakelite(Glass fiber mixed) /PBT
Operating temperature: -60℃ - +200℃
Insulation resistance: Normal ≥1000MΩ Moistheat ≥20MΩ
Contact resistance: 0.8-5mΩ

Φ1.0 Φ1.5 Φ2 Φ3
5A 10A 20A 40A





Φ1.0 Φ1.5 Φ2 Φ3
5mΩ 2.5mΩ 1.6mΩ 0.8mΩ



Product pictures:

2PM Series 2PM27K7QB1 Circular Electrical Connectors Straight Cable Plug 22PM Series 2PM27K7QB1 Circular Electrical Connectors Straight Cable Plug 32PM Series 2PM27K7QB1 Circular Electrical Connectors Straight Cable Plug 42PM Series 2PM27K7QB1 Circular Electrical Connectors Straight Cable Plug 5
