MS27508 Series connectors，MS27508E18B35PLB,MS27508 connectors

  • MS27508 Series connectors，MS27508E18B35PLB,MS27508 connectors
  • MS27508 Series connectors，MS27508E18B35PLB,MS27508 connectors
  • MS27508 Series connectors，MS27508E18B35PLB,MS27508 connectors
  • MS27508 Series connectors，MS27508E18B35PLB,MS27508 connectors
Place of Origin China
Brand Name HIGH WOOD
Certification AS9001
Model Number MS27508E18B35PLB
Minimum Order Quantity 100pcs
Price 10＄--150＄
Packaging Details standard export package
Delivery Time 2--9weeks
Payment Terms L\C,T\T,, Western Union
Supply Ability 100,000pcs per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Connector Type Circular, Receptacle Max Operating Temperature 200 °C
Min Operating Temperature -65 °C Voltage Rating 500 V
Termination Crimp
Leave a Message
Product Description

MS27508E18B35PLB:



Shell components are impact extruded or machined bar stock aluminum. Standard plating on shell components is cadmium over nickel. Many finishes are optional . Hermetic seal receptacles are available in carbon steel or stainless steel shells. Dependable 5 key/keyway polarization with bayonet lock coupling is incorporated to aid and assure positive mating. Insert material is a rigid dielectric with excellent electrical characteristics, providing durable protection for molded-in solder type contacts. Contrasting letter
or number designations are used on insert faces. A fluorinated silicone interfacial seal wafer is featured on the mating face of “crimp type pin” inserts. This assures complete electrical isolation of pins when connector halves are mated. In addition, a main joint gasket is installed in the receptacle for
moisture sealing between connector halves. Both features are also available for hermetic receptacles.



Part number:



MS27508 Series connectors，MS27508E18B35PLB,MS27508 connectors 0



MS Number

MS Number designates MIL-DTL-38999, Series I LJT Lanyard Release Plug



Service Class

E for environmental crimp applications (inactive for new design)

T for environmental crimp applications with serrations on rear threads of shell



Shell Size MIL-DTL-38999, sizes 11 through 25



Finish

B designates corrosion resistant olive drab cadmium plated aluminum, 500 hour extended salt spray, EMI shielding effectiveness –50dB @ 10 GHz specification min., 175°C

F designates electroless nickel plated aluminum, 48 hour salt spray, EMI shielding effectiveness –65dB @ 10 GHz500 specification min., 200°C These are standard finishes. Consult Amphenol Aerospace for variations.



Insert Arrangement

MIL-DTL-38999, see insert identification chart on page 40.



Contact Style

P designates Lanyard Release plug with pin contacts

S designates Lanyard Release plug with socket contacts



Polarizing Postion

For alternate positions of connector (to prevent crossmating) see LJT key/keyway rotation description on page 5. (No letter is required for normal)



Detail:



MS27508 Series connectors，MS27508E18B35PLB,MS27508 connectors 1

product show:



MS27508 Series connectors，MS27508E18B35PLB,MS27508 connectors 2

MS27508 Series connectors，MS27508E18B35PLB,MS27508 connectors 3

MS27508 Series connectors，MS27508E18B35PLB,MS27508 connectors 4

MS27508 Series connectors，MS27508E18B35PLB,MS27508 connectors 5
